View In:   ArcGIS Online Map Viewer

Name: USNationalGrid1000

Display Field: GRID100K

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This layer represents a 1,000 by 1,000 meter United States National Grid (USNG) for Florida. The USNG is an alpha-numeric reference system based on the UTM coordinate system and is similar to the Military Grid Reference System. Use of the USNG ensures a uniform grid mapping and positional reporting system for search and rescue, emergency planning, response, and recovery.

Copyright Text: University of Florida GeoPlan Center

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 0

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 417078.8997704126
YMin: 1171546.9033364877
XMax: 654986.6634552442
YMax: 1409453.8130204082
Spatial Reference: 102659  (2237)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [208, 252, 207, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: true
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: false
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• X_LWRLFT ( type: esriFieldTypeDouble, alias: X_LWRLFT, editable: true, nullable: true, defaultValue: null, modelName: X_LWRLFT )
• Y_LWRLFT ( type: esriFieldTypeDouble, alias: Y_LWRLFT, editable: true, nullable: true, defaultValue: null, modelName: Y_LWRLFT )
• GRID100K ( type: esriFieldTypeString, alias: GRID100K, editable: true, nullable: true, length: 2, defaultValue: null, modelName: GRID100K )
• GRID10K ( type: esriFieldTypeString, alias: GRID10K, editable: true, nullable: true, length: 3, defaultValue: null, modelName: GRID10K )
• GRID1000M ( type: esriFieldTypeString, alias: GRID1000M, editable: true, nullable: true, length: 5, defaultValue: null, modelName: GRID1000M )
• LABEL ( type: esriFieldTypeString, alias: LABEL, editable: true, nullable: true, length: 7, defaultValue: null, modelName: LABEL )
• DESCRIPT ( type: esriFieldTypeString, alias: DESCRIPT, editable: true, nullable: true, length: 7, defaultValue: null, modelName: DESCRIPT )
• FGDLAQDATE ( type: esriFieldTypeDate, alias: FGDLAQDATE, editable: true, nullable: true, length: 8, defaultValue: null, modelName: FGDLAQDATE )
• AUTOID ( type: esriFieldTypeDouble, alias: AUTOID, editable: true, nullable: true, defaultValue: null, modelName: AUTOID )
• Shape__Area ( type: esriFieldTypeDouble, alias: SHAPE.STArea(), editable: false, nullable: true, defaultValue: null, modelName: SHAPE.STArea(), required: true )
• Shape__Length ( type: esriFieldTypeDouble, alias: SHAPE.STLength(), editable: false, nullable: true, defaultValue: null, modelName: SHAPE.STLength(), required: true )

Templates:

• Name: USNationalGrid1000
  Description:
  Prototype:
  AUTOID: null
  FGDLAQDATE: null
  X_LWRLFT: null
  Y_LWRLFT: null
  GRID100K: null
  GRID10K: null
  GRID1000M: null
  LABEL: null
  DESCRIPT: null

  Drawing Tool: esriFeatureEditToolPolygon

Capabilities: Query

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: false

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Child Resources:

Supported Operations:   Query   Query Analytic   Append   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
