View In:   ArcGIS Online Map Viewer

Name: PLSSTownship

Display Field: PLSSID

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This feature class depicts PLSS Township Range Divisions for Hillsborough County, Florida, based on local survey data.This feature class contains polygons representing the Public Land Survey System (PLSS) sections. The data was from official cadastral surveys and is compliant with FGDC Cadastral Data Content Standards.The PLSS, also known as the "Township and Range" system, is the method used to divide land in the United States for sale and settlement. Townships are rectangular areas, typically 6 miles square, and are the horizontal rows in the PLSS grid. Each township is divided into 36 sections, each approximately 1 square mile (640 acres) in size. Sections can be further subdivided into quarter sections, quarter-quarter sections, or irregular government lots. Sections are numbered sequentially within a township, starting in the northeast corner and moving west and then east in a checkerboard pattern. The PLSS is a system of rectangular grids, but in practice, it can be difficult to maintain perfect squares due to natural terrain and other factors. The PLSS is the basis for federal land ownership and is used to describe land locations in many parts of the United States.

Copyright Text: Compiled by the Bureau of Land Management (BLM), National Operations Center (NOC), OC-530

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 0

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 446337.2395475805
YMin: 1204020.3748067394
XMax: 638615.3251349963
YMax: 1396323.5200553238
Spatial Reference: 102659  (2237)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [252, 181, 226, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: true
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: false
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• PLSSID ( type: esriFieldTypeString, alias: PLSS ID, editable: true, nullable: true, length: 15, defaultValue: null, modelName: PLSSID )
• TR ( type: esriFieldTypeString, alias: TR, editable: true, nullable: true, length: 10, defaultValue: null, modelName: TR )
• Township ( type: esriFieldTypeString, alias: Township/Range, editable: true, nullable: true, length: 2, defaultValue: null, modelName: Township )
• TownshipDirection ( type: esriFieldTypeString, alias: Township Direction, editable: true, nullable: true, length: 5, defaultValue: null, modelName: TownshipDirection )
• Range ( type: esriFieldTypeString, alias: Range, editable: true, nullable: true, length: 2, defaultValue: null, modelName: Range )
• RangeDirection ( type: esriFieldTypeString, alias: Range Direction, editable: true, nullable: true, length: 4, defaultValue: null, modelName: RangeDirection )
• PrincipalMeridian ( type: esriFieldTypeString, alias: Principal Meridian, editable: true, nullable: true, length: 20, defaultValue: null, modelName: PrincipalMeridian )
• PrincipalMeridianCode ( type: esriFieldTypeSmallInteger, alias: Principal Meridian Code, editable: true, nullable: true, defaultValue: null, modelName: PrincipalMeridianCode )
• State ( type: esriFieldTypeString, alias: State Abbreviation, editable: true, nullable: true, length: 2, defaultValue: null, modelName: State )
• Shape__Area ( type: esriFieldTypeDouble, alias: SHAPE.STArea(), editable: false, nullable: true, defaultValue: null, modelName: SHAPE.STArea(), required: true )
• Shape__Length ( type: esriFieldTypeDouble, alias: SHAPE.STLength(), editable: false, nullable: true, defaultValue: null, modelName: SHAPE.STLength(), required: true )

Templates:

• Name: PLSSTownship
  Description:
  Prototype:
  State: null
  PrincipalMeridianCode: null
  PLSSID: null
  TR: null
  Township: null
  TownshipDirection: null
  Range: null
  RangeDirection: null
  PrincipalMeridian: null

  Drawing Tool: esriFeatureEditToolPolygon

Capabilities: Query

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: false

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Child Resources:

Supported Operations:   Query   Query Analytic   Append   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
