View In:   ArcGIS Online Map Viewer

Name: .BaseFloodElevation

Display Field: DFIRM_ID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This polyline dataset contains information about the Base Flood Elevations (BFE) within a study area. BFE lines indicate the rounded whole-foot water surface elevation of the 1-percent-annual-chance flood. The spatial elements representing BFE features are lines extending from Special Flood Hazard Area (SFHA) boundary to SFHA boundary. The BFE lines will have no visible gaps or overshoots between the SFHA boundary and the end of the BFE line at the publication scale of the DFIRM. However, the ends of the BFE lines are not necessarily snapped precisely to the SFHA boundary. Each BFE is represented by a single line. The Base Flood Elevation (BFE) information is required for any digital data where BFE lines will be shown on the corresponding Flood Insurance Rate Map (FIRM). Normally if there are any riverine AE zones, BFE lines are required. While BFE lines are depicted as wavy lines on the hardcopy FIRM, they should be primarily straight lines in the spatial data, although they may bend consistent with procedures described in Volume 1 of these Guidelines. The Digital Flood Insurance Rate Map (DFIRM) Database depicts flood risk information and supporting data used to develop the risk data. The primary risk classifications used are the 1-percent-annual-chance flood event (100 year), the 0.2-percent-annual-chance flood event (500 year), and areas of minimal flood risk. The DFIRM Database is derived from Flood Insurance Studies (FISs), previously published Flood Insurance Rate Maps (FIRMs), flood hazard analyses performed in support of the FISs and FIRMs, and new mapping data, where available. The FISs and FIRMs are published by FEMA. This dataset is an update to the DFIRM_BFE_NOV18 layer.

Copyright Text: Federal Emergency Management Agency (FEMA) Hillsborough County, FL

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 0

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 446765.2961061634
YMin: 1204313.0228434876
XMax: 638297.2814797461
YMax: 1395160.515491575
Spatial Reference: 102659  (2237)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [140, 128, 64, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: false
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• DFIRM_ID ( type: esriFieldTypeString, alias: DFIRM_ID, editable: true, nullable: true, length: 6, defaultValue: null, modelName: DFIRM_ID )
• VERSION_ID ( type: esriFieldTypeString, alias: VERSION_ID, editable: true, nullable: true, length: 11, defaultValue: null, modelName: VERSION_ID )
• BFE_LN_ID ( type: esriFieldTypeString, alias: BFE_LN_ID, editable: true, nullable: true, length: 32, defaultValue: null, modelName: BFE_LN_ID )
• ELEV ( type: esriFieldTypeDouble, alias: ELEV, editable: true, nullable: true, defaultValue: null, modelName: ELEV )
• LEN_UNIT ( type: esriFieldTypeString, alias: LEN_UNIT, editable: true, nullable: true, length: 16, defaultValue: null, modelName: LEN_UNIT )
• V_DATUM ( type: esriFieldTypeString, alias: V_DATUM, editable: true, nullable: true, length: 17, defaultValue: null, modelName: V_DATUM )
• SOURCE_CIT ( type: esriFieldTypeString, alias: SOURCE_CIT, editable: true, nullable: true, length: 21, defaultValue: null, modelName: SOURCE_CIT )
• LastUpdate ( type: esriFieldTypeDate, alias: LastUpdate, editable: true, nullable: true, length: 8, defaultValue: null, modelName: LastUpdate )
• Shape__Length ( type: esriFieldTypeDouble, alias: SHAPE.STLength(), editable: false, nullable: true, defaultValue: null, modelName: SHAPE.STLength(), required: true )

Templates:

• Name: .BaseFloodElevation
  Description:
  Prototype:
  LastUpdate: null
  SOURCE_CIT: null
  DFIRM_ID: null
  VERSION_ID: null
  BFE_LN_ID: null
  ELEV: null
  LEN_UNIT: null
  V_DATUM: null

  Drawing Tool: esriFeatureEditToolLine

Capabilities: Query

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: false

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Child Resources:

Supported Operations:   Query   Query Analytic   Append   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
