Name: Flowline

Display Field: GNIS_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: The National Hydrography Dataset (NHD) is a feature-based database that interconnects and uniquely identifies the stream segments or reaches that make up the nation's surface water drainage system. NHD data was originally developed at 1:100,000-scale and exists at that scale for the whole country. This high-resolution NHD, generally developed at 1:24,000/1:12,000 scale, adds detail to the original 1:100,000-scale NHD. (Data for Alaska, Puerto Rico and the Virgin Islands was developed at high-resolution, not 1:100,000 scale.) Local resolution NHD is being developed where partners and data exist. The NHD contains reach codes for networked features, flow direction, names, and centerline representations for areal water bodies. Reaches are also defined on waterbodies and the approximate shorelines of the Great Lakes, the Atlantic and Pacific Oceans and the Gulf of Mexico. The NHD also incorporates the National Spatial Data Infrastructure framework criteria established by the Federal Geographic Data Committee.

Copyright Text: United States Geological Survey (USGS) Florida Department of Environmental Protection (FDEP) Hillsborough County, FL

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 407799.01609924436
YMin: 1179735.8029691577
XMax: 638600.4770675786
YMax: 1396235.5612417385
Spatial Reference: 102659  (2237)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: FTYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSLSSolid
Color: [130, 130, 130, 255]
Width: 1
Default Label: <all other values>
UniqueValueInfos:
• Value: 334
  Label: Connector
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [252, 230, 207, 255]
  Width: 1
• Value: 336
  Label: CanalDitch
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [238, 179, 252, 255]
  Width: 1
• Value: 420
  Label: Underground Conduit
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [179, 252, 188, 255]
  Width: 1
• Value: 428
  Label: Pipeline
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [179, 220, 252, 255]
  Width: 1
• Value: 460
  Label: StreamRiver
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [252, 197, 221, 255]
  Width: 1
• Value: 468
  Label: Drainageway
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [189, 252, 240, 255]
  Width: 1
• Value: 558
  Label: ArtificialPath
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [245, 252, 182, 255]
  Width: 1
• Value: 566
  Label: Coastline
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [189, 187, 252, 255]
  Width: 1
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: FTYPE

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• PERMANENT_IDENTIFIER ( type: esriFieldTypeString, alias: Permanent_Identifier, length: 40 )
• FDATE ( type: esriFieldTypeDate, alias: FDate, length: 8 )
• RESOLUTION ( type: esriFieldTypeInteger, alias: Resolution )
• GNIS_ID ( type: esriFieldTypeString, alias: GNIS_ID, length: 10 )
• GNIS_NAME ( type: esriFieldTypeString, alias: GNIS_Name, length: 65 )
• LENGTHKM ( type: esriFieldTypeDouble, alias: LengthKm )
• REACHCODE ( type: esriFieldTypeString, alias: ReachCode, length: 14 )
• FLOWDIR ( type: esriFieldTypeInteger, alias: FlowDir )
• WBAREA_PERMANENT_IDENTIFIER ( type: esriFieldTypeString, alias: WBArea_Permanent_Identifier, length: 40 )
• FTYPE ( type: esriFieldTypeInteger, alias: FType )
• FCODE ( type: esriFieldTypeInteger, alias: FCode )
• MAINPATH ( type: esriFieldTypeInteger, alias: MainPath )
• INNETWORK ( type: esriFieldTypeInteger, alias: InNetwork )
• VISIBILITYFILTER ( type: esriFieldTypeInteger, alias: VisibilityFilter )
• PARENT_FEATURE ( type: esriFieldTypeString, alias: PARENT_FEATURE, length: 50 )
• ENABLED ( type: esriFieldTypeSmallInteger, alias: ENABLED )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )
• LastUpdate ( type: esriFieldTypeDate, alias: LastUpdate, length: 8 )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Types:

ID: 334
Name: Connector
Domains:
• RESOLUTION:
  Coded Values: [1: Local] , [2: High] , [3: Medium]
• FLOWDIR:
  Coded Values: [0: Uninitialized] , [1: WithDigitized]
• FCODE:
  Coded Values: [33400: Connector]
• ENABLED:
  Coded Values: [0: False] , [1: True]

---

ID: 336
Name: CanalDitch
Domains:
• RESOLUTION:
  Coded Values: [1: Local] , [2: High] , [3: Medium]
• FLOWDIR:
  Coded Values: [0: Uninitialized] , [1: WithDigitized]
• FCODE:
  Coded Values: [33600: Canal Ditch] , [33601: Canal Ditch: Canal Ditch Type = Aqueduct] , [33603: Canal Ditch: Canal Ditch Type = Stormwater]
• ENABLED:
  Coded Values: [0: False] , [1: True]

---

ID: 420
Name: Underground Conduit
Domains:
• RESOLUTION:
  Coded Values: [1: Local] , [2: High] , [3: Medium]
• FLOWDIR:
  Coded Values: [0: Uninitialized] , [1: WithDigitized]
• FCODE:
  Coded Values: [42000: Underground Conduit] , [42001: Underground Conduit: Positional Accuracy = Definite] , [42002: Underground Conduit: Positional Accuracy = Indefinite] , ...1 more...
• ENABLED:
  Coded Values: [0: False] , [1: True]

---

ID: 428
Name: Pipeline
Domains:
• RESOLUTION:
  Coded Values: [1: Local] , [2: High] , [3: Medium]
• FLOWDIR:
  Coded Values: [0: Uninitialized] , [1: WithDigitized]
• FCODE:
  Coded Values: [42800: Pipeline] , [42816: Pipeline: Pipeline Type = Aqueduct] , [42801: Pipeline: Pipeline Type = Aqueduct; Relationship to Surface = At or Near] , ...19 more...
• ENABLED:
  Coded Values: [0: False] , [1: True]

---

ID: 460
Name: StreamRiver
Domains:
• RESOLUTION:
  Coded Values: [1: Local] , [2: High] , [3: Medium]
• FLOWDIR:
  Coded Values: [0: Uninitialized] , [1: WithDigitized]
• FCODE:
  Coded Values: [46000: Stream/River] , [46003: Stream/River: Hydrographic Category = Intermittent] , [46006: Stream/River: Hydrographic Category = Perennial] , ...1 more...
• ENABLED:
  Coded Values: [0: False] , [1: True]

---

ID: 468
Name: Drainageway
Domains:
• RESOLUTION:
  Coded Values: [1: Local] , [2: High] , [3: Medium]
• FLOWDIR:
  Coded Values: [0: Uninitialized] , [1: WithDigitized]
• FCODE:
  Coded Values: [468: Drainageway]
• ENABLED:
  Coded Values: [0: False] , [1: True]

---

ID: 558
Name: ArtificialPath
Domains:
• RESOLUTION:
  Coded Values: [1: Local] , [2: High] , [3: Medium]
• FLOWDIR:
  Coded Values: [0: Uninitialized] , [1: WithDigitized]
• FCODE:
  Coded Values: [55800: Artificial Path]
• ENABLED:
  Coded Values: [0: False] , [1: True]

---

ID: 566
Name: Coastline
Domains:
• RESOLUTION:
  Coded Values: [1: Local] , [2: High] , [3: Medium]
• FLOWDIR:
  Coded Values: [0: Uninitialized] , [1: WithDigitized]
• FCODE:
  Coded Values: [56600: Coastline]
• ENABLED:
  Coded Values: [0: False] , [1: True]

---

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
